SMA4033 NPN Darlington

SMA4033 NPN Darlington With built-in flywheel diode External dimensions B SMA Absolute maximum ratings Symbol Ratings VCBO 120 VCEO 100 VEBO 6 IC 2 ICP 4 (PW≤1ms, Du≤50%) IB 0.2 IF 2 (PW≤0.5ms, Du≤25%) IFSM 4 (PW≤10ms, Single pulse) VR 120 4 (Ta=25°C) PT 20 (Tc=25°C) Tj 150 Tstg 40 to +150 sEquivalent circuit diagram 23 4 9 10 11 (Ta=25°C) Unit V V V A A A A A V W °C °C Electrical characteristics Specification Symbol min.
