Part number: FX803
Manufacturer: Sanyo Semicon Device
File Size: 125.00 KB
Datasheet: FX803_SanyoSemiconDevice.pdf
Description: DC-DC Converter

FX803 Product details

Features

Complex type of a low saturation voltage, high speed switching and large current NPN transistor and a fast recovery and low forward voltage Schottky barrier diode facilitating high-sensity mounting.
The FX803 is composed of 2 chips, one being equivalent to the 2SB1628 and the other the SB20W03P, placed in one package. Package Dimensions unit:mm 2126 [FX803] Electrical Connection 1:Base 2:Emitter 3:Anode1 4:Anode2 5:Cathode 6:Collector (Top view) 1:Base 2:Emitter 3:Anode1 4:Anode2.
