SP9504 - Quad / 12-Bit / Voltage Output D/A Converter

Sipex

📥 Download Datasheet

SP9504 Datasheet Preview — Preview of SP9504 PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	SP9504
Manufacturer	Sipex
File Size	184.84 KB
Description	Quad / 12-Bit / Voltage Output D/A Converter
Datasheet	SP9504_SipexCorporation.pdf

SP9504 Product details

Description

The SP9504 is a low power replacement for the popular SP9345, Quad 12-Bit Digital-to-Analog Converter.

Features

+4.5V output swings when using ±5 volt supplies. The converter is doublebuffered for easy microprocessor interface. Each 12-bit DAC is independently addressable and all DACS may be simultaneously updated using a single transfer command. The output settlingtime is specified at 4µs. The SP9504 is available in 28.
pin SOIC and plastic DIP packages, specified over commercial temperature range. Ref In INPUT.
