CLS10 Datasheet - Sumida Corporation

CLS10 DC-DC CONVERTER

DC-DC CONVERTER SMD CLQ104 10.9 MAX. DIMENSIONS(mm) LAND PATTERNS(mm) 7.0 CONSTRUCTION 4.5 MAX. 7.5 3-2.0 6.8 11.9 MAX. 2.5 0.5 12.0 2.0 6.0 9.0 1.2 ✽ In order to prevent shortcircuiting, a solder resist is recommended. Solder Resist ✽ K Specifications Max. Operating frequency 500kHz Max. Operating Power 800mW @ 100kHz 2.0W @ 300kHz 3.0W @ 500kHz 500kHz 800mW @ 100kHz 2.0W @ 300kHz 3.0W @ 500kHz APPLICATION 1. Digital video camera CLS10 www.DataSheet4U.com DIMENSIONS(mm) LAN.

CLS10_SumidaCorporation.pdf

Preview of CLS10 PDF

Datasheet Details

Part number:

CLS10

Manufacturer:

Sumida Corporation

File Size:

128.73 KB

Description:

Dc-dc converter.
