KBPC104, KBPC1005 SILICON BRIDGE RECTIFIERS

Sunmate

Description

KBPC1005 - KBPC110 SILICON BRIDGE RECTIFIERS VOLTAGE RANGE: 50 - 1000V CURRENT: 3.0 A .

📥 Download Datasheet

KBPC104 Datasheet Preview — This datasheet PDF includes multiple part numbers: KBPC104, KBPC1005. Please refer to the document for exact specifications by model.

Datasheet Specifications

Part number: KBPC104, KBPC1005
Manufacturer: Sunmate
File Size: 236.04 KB
Datasheet: KBPC1005-Sunmate.pdf
Description: SILICON BRIDGE RECTIFIERS
Note: This datasheet PDF includes multiple part numbers: KBPC104, KBPC1005.
Please refer to the document for exact specifications by model.

Features

* ! The plastic package carries Underwriters Laboratory ! Flammability Classification 94V-0 ! Ideal for printed circuit boards ! Low reverse leakage ! High forward surge current capability ! High temperature soldering guaranteed: 260 C/10 seconds,at 5 lbs. (2.3kg) tension Mechanical Data ! Case: Molde
