2SK2267 - N-CHANNEL MOS TYPE TRANSISTOR

2SK2267 Description

2SK2267 TOSHIBA Field Effect Transistor Silicon N Channel MOS Type (L2 *π *MOSV) 2SK2267 Chopper Regulator, DC *DC Converter and.

2SK2267 Features

* as to environmental matters such as the RoHS compatibility of Product. Please use Product in compliance with all applicable laws and regulations that regulate the inclusion or use of controlled substances, including without limitation, the EU RoHS Directive. TOSHIBA assumes no liability for damages

2SK2267 Applications

* Unit: mm z 4-V gate drive z Low drain
* source ON-resistance : RDS (ON) = 8 mΩ (typ. ) z High forward transfer admittance : |Yfs| = 60 S (typ. ) z Low leakage current : IDSS = 100 μA (max) (VDS = 60 V) z Enhancement mode : Vth = 0.8 to 2.0 V (VDS = 10 V, ID = 1 mA) Absolute Maximum Ra

📥 Download Datasheet

Preview of 2SK2267 PDF
datasheet Preview Page 2 datasheet Preview Page 3
