TK160F10N1L - Silicon N-Channel MOSFET

Toshiba

📥 Download Datasheet

TK160F10N1L Datasheet Preview — Preview of TK160F10N1L PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	TK160F10N1L
Manufacturer	Toshiba ↗
File Size	489.28 KB
Description	Silicon N-Channel MOSFET
Datasheet	TK160F10N1L-Toshiba.pdf

TK160F10N1L Product details

Features

(1) AEC-Q101 qualified (2) Low drain-source on-resistance: RDS(ON) = 2.0 mΩ (typ. ) (VGS = 10 V) (3) Low leakage current: IDSS = 10 µA (max) (VDS = 100 V) (4) Enhancement mode: Vth = 2.5 to 3.5 V (VDS = 10 V, ID = 1 mA) 3. Packaging and Internal Circuit TK160F10N1L TO-220SM(W) 1: Gate 2: Drain (Heatsink) 3: Source ©2016-2020 Toshiba Electronic Devices & Storage Corporation 1 Start of commercial production 2016-04 2020-06-24 Rev.6.0 TK160F10N1L 4. Absolute Maximum Ratings (Note) (Ta = 25 .
