* TrenchFET® Power MOSFET
* 100 % Rg Tested APPLICATIONS
* For Mobile Computing - Load Switch - Notebook Adaptor Switch - DC/DC Converter ABSOLUTE MAXIMUM RATINGS (TA = 25 °C, unless otherwise noted) Parameter Symbol Limit Drain-Source Voltage Gate-Source Voltage Continu
VB3407A
VBsemi
346.29 KB
P-channel mosfet.
VB3407A P-Channel 30 V (D-S) MOSFET www.VBsemi.com PRODUCT SUMMARY VDS (V) RDS(on) () Max. 0.034 at VGS = - 10 V - 30 0.038 at VGS = - 6 V 0.
