✔ VBP112MC100 Features
- Low figure-of-merit (FOM) Ron x Qg
- Low input capacitance (Ciss)
- Reduced switching and conduction losses
- Ultra low gate charge (Qg)
- Avalanche energy rated (UIS)
✔ VBP112MC100 Application
- Server and telecom power supplies
- Switch mode power supplies (SMPS)
- Power factor correction power supp
PDF File Details
VBsemi manufacturer logo
Part number:
VBP112MC100
Manufacturer:
VBsemi
File Size:
835.24kb
Download:
📄 Datasheet
Description:
N-channel mosfet.
