PCA0445A - LOW COST - HIGH PERFORMANCE PHASE LOCKED LOOP

This page provides the datasheet information for the PCA0445A, a member of the PCA0445A_Z LOW COST - HIGH PERFORMANCE PHASE LOCKED LOOP family.

Datasheet Summary

Description

NOTES: Reference Oscillator Signal: 5 MHz

Features

Frequency Range: 420 - 470 MHz.
Step Size: 100 KHz.
cPLL - Style Package.

Z-Communications

📥 Download Datasheet

Datasheet Details

Part number	PCA0445A
Manufacturer	Z-Communications
File Size	88.47 KB
Description	LOW COST - HIGH PERFORMANCE PHASE LOCKED LOOP
Datasheet	PCA0445A Datasheet
