75150 DUAL LINE DRIVER

75150 Description

SN75150 DUAL LINE DRIVER D Meets or Exceeds the Requirement of TIA/EIA-232-F and ITU Recommendation V.28 D Withstands Sustained Output Short Circuit .
The SN75150 is a monolithic dual line driver designed to satisfy the requirements of the standard interface between data-terminal equipment and data-c.

75150 Applications

* are in data-transmission systems using relatively short single lines, in level translators, and for driving MOS devices. The logic input is compatible with most TTL families. Operation is from 12-V and
* 12-V power supplies. The SN75150 is characterized for operation from 0°C to 70°C. logic
