DLPC231S-Q1

Automotive Digital Micromirror Controller

DLPC231S-Q1 Features

* Qualified for automotive applications

* AEC-Q100 qualified with the following results:

* Device temperature grade 2:

* 40°C to +105°C ambient operating temperature

* Device HBM ESD classification level 2

* Device CDM ESD classification level C4B

DLPC231S-Q1 General Description

The DLPC23xS-Q1 Digital Micromirror Display (DMD) controller for automotive applications is used in chipsets for interior and exterior display applications with a functional safety requirement (such as augmented reality HUDs and windshield clusters). The DLP5530S-Q1 chipset includes a 0.55” DMD and.

DLPC231S-Q1 Datasheet (3.02 MB)

Preview of DLPC231S-Q1 PDF

Datasheet Details

Part number:

DLPC231S-Q1

Manufacturer:

Texas Instruments ↗

File Size:

3.02 MB

Description:

Automotive digital micromirror controller.
DLPC230S-Q1, DLPC231S-Q1 DLPS201C

* AUGUST 2020

* REVISED SEPTEMBER 2023 DLPC23xS-Q1 Automotive Digital Micromirror Device Controller .
