Part number: LM49153
Manufacturer: Texas Instruments (https://www.ti.com/)
File Size: 1.79MB
Download: π Datasheet
Description: Mono Audio Subsystem
1
*23 Class G Ground Referenced Headphone Outputs
* High Efficiency Class D Amplifier with Spread Spectrum
* No Clip
* Speaker Protection
* Noise Gate.
* Feature Phones
* Smart Phones
KEY SPECIFICATIONS
* Class G Headphone Amplifier, HPVDD = 1.8V, RL = 32Ξ©
The LM49153 is a fully integrated audio subsystem designed for portable handheld applications such as cellular phones. Part of Texas Instruments' PowerWise family of products, the LM49153 combines an earpiece switch, a high efficiency 25mW class G he.
Image gallery
