74HC4514D Datasheet, Decoder/demultiplexer, nexperia

74HC4514D Features

• Decoder/demultiplexer
• Wide supply voltage range from 2.0 to 6.0 V
• CMOS low power dissipation
• High noise immunity
• Input levels:
• For 74HC4514: CMOS level

PDF File Details

Part number:

74HC4514D

Manufacturer:

nexperia ↗

File Size:

271.90kb

Download:

📄 Datasheet

Description:

4-to-16 line decoder/demultiplexer. The 74HC4514; 74HCT4514 is a 4-to-16 line decoder/demultiplexer having four binary weighted address inputs (A0 to A3), with latches,

74HC4514D Application

• Applications
• Digital multiplexing
• Address decoding
• Hexadecimal/BCD decoding Nexperia 74HC4514; 74HCT4514 4-to-16 lin
