HEF4013B Datasheet, Flip-flop, nexperia

HEF4013B Features

• Flip-flop
• Wide supply voltage range from 3.0 V to 15.0 V
• CMOS low power dissipation
• High noise immunity
• Tolerant of slow clock rise and fall times

PDF File Details

Part number:

HEF4013B

Manufacturer:

nexperia ↗

File Size:

246.71kb

Download:

📄 Datasheet

Description:

Dual d-type flip-flop. The HEF4013B is a dual D-type flip-flop with set and reset; positive-edge trigger. Inputs include clamp diodes. This enables the use

HEF4013B Application

• Applications
• Counters and dividers
• Registers
• Toggle flip-flops 4. Ordering information Table 1. Ordering information
