BLF888A
BLF888A is Power LDMOS transistor manufactured by Ampleon.
BLF888A; BLF888AS
UHF power LDMOS transistor
Rev. 6
- 1 September 2015
Product data sheet
1. Product profile
1.1 General description
A 600 W LDMOS RF power transistor for broadcast transmitter applications and industrial applications. The excellent ruggedness of this device makes it ideal for digital and analog transmitter applications.
Table 1. Application information
RF performance at VDS = 50 V unless otherwise specified.
Mode of operation f
PL(AV)
(MHz)
(W)
PL(M) (W)
Gp (dB)
D (%)
RF performance in a mon source narrowband test circuit
CW 650
- 600 20 67
CW (42 V)
- 500 20 69
2-tone, class-AB pulsed, class-AB [1] f1 = 860; f2 = 860.1 860
- 21 46
- 600...
