Dcc No.:400040432 Issued Date: Jun,24, 2010 Model No.: N156B6-L0A Approval TFT LCD Approval Specification MODEL NO.: N156B6-L0A Customer : Approved by : Note : ____ 2010-06-28 14:23:38 Director Accept 1 / 33 Version 2.1 Dcc No.:400040432 Issued Date: Jun,24, 2010 Model No.: N156B6-L0A Approval 1. GENERAL DESCRIPTION 1.1 OVERVIEW N156B6-L0B is a 15.6” (15.547” diagonal) TFT Liquid Crystal Display module with LED Backlight unit and 40 pins LVDS interface. This module supports 1366 x 768 HD mode and can display 262,144 colors. The optimum viewing angle is at 6 o’clock direction. 1.2 Features - HD (1366 x 768 pixels) resolution - 3.3V LVDS (Low Voltage Differential...
