N156B6-L0B Description
1.1 OVERVIEW N156B6-L0B is a 15.6” (15.547” diagonal) TFT Liquid Crystal Display module with LED Backlight unit and 40 pins LVDS interface. This module supports 1366 x 768 HD mode and can display 262,144 colors. The optimum viewing angle is at 6 o’clock direction.
N156B6-L0B Key Features
- HD (1366 x 768 pixels) resolution
- 3.3V LVDS (Low Voltage Differential Signaling) interface with 1 pixel/clock
- LED converter embedded
- TFT LCD Notebook
- 1.5 MECHANICAL SPECIFICATIONS
- Note (1) Please refer to the attached drawings for more information of front and back outline dimensions
