MMBT5551 - NPN Transistor

Key Features

  • Epitaxial Planar Die Construction.
  • Complementary PNP Type Available (MMBT5401).
  • Ideal for Low Power Amplification and Switching.
  • Lead, Halogen and Antimony Free, RoHS Compliant.
  • "Green" Device (Notes 2 and 3) MMBT5551 NPN SMALL SIGNAL.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
MMBT5551 NPN Transistor Formosa MS
MMBT5551 Silicon NPN Transistor NTE
MMBT5551 SMD High Voltage Transistor TAITRON
MMBT5551 NPN Transistor GOOD-ARK
MMBT5551 NPN Plastic Encapsulated Transistor SeCoS

Other Datasheets by Diodes Incorporated

Part Number Description
MMBT5401 150V PNP HIGH-VOLTAGE TRANSISTOR
MMBT123S 1A NPN SURFACE MOUNT TRANSISTOR
MMBT2222AT NPN SMALL SIGNAL SURFACE MOUNT TRANSISTOR
MMBT2907A 60V PNP Transistor
MMBT2907AT PNP Transistor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Features • Epitaxial Planar Die Construction • Complementary PNP Type Available (MMBT5401) • Ideal for Low Power Amplification and Switching • Lead, Halogen and Antimony Free, RoHS Compliant • "Green" Device (Notes 2 and 3) MMBT5551 NPN SMALL SIGNAL SURFACE MOUNT TRANSISTOR Mechanical Data • Case: SOT-23 • Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0 • Moisture Sensitivity: Level 1 per J-STD-020D • Terminal Connections: See Diagram • Terminals: Solderable per MIL-STD-202, Method 208 • Lead Free Plating (Matte Tin Finish annealed over Alloy 42 leadframe). • Marking Information: See Page 3 • Ordering Information: See Page 3 • Weight: 0.
