Datasheet Summary
SMD Type
P-Channel MOSFET AO4409 (KO4409)
- Features
- VDS (V) =-30V
- ID =-15 A (VGS =-10V)
- RDS(ON) ＜ 7.5mΩ (VGS =-10V)
- RDS(ON) ＜ 12mΩ (VGS =-4.5V)
SOP-8
+0.04 0.21 -0.02
MOSFET
1.50 0.15
1 Source 2 Source 3 Source 4 Gate
5 Drain 6 Drain 7 Drain 8 Drain
-...
