AO4454 Overview
Key Features
- VDS (V) = 100V
- ID = 6.5 A (VGS = 10V)
- RDS(ON) ＜ 36mΩ (VGS = 10V)
- RDS(ON) ＜ 43mΩ (VGS = 7V) SOP-8 +0.04 0.21 -0.02 D MOSFET 1.50 0.15 1 Source 2 Source 3 Source 4 Gate 5 Drain 6 Drain 7 Drain 8 Drain G S
| Part | AO4454 |
|---|---|
| Description | N-Channel MOSFET |
| Category | MOSFET |
| Manufacturer | Kexin Semiconductor |
| Size | 1.07 MB |
