HVD145
Features
- An optimal solution for antenna switching in mobile phones.
- Low capacitance. (C = 0.45 p F max)
- Low forward resistance. (rf = 1.8 Ω max)
- Super small Flat Lead Package (SFP) is suitable for surface mount design.
Ordering Information
Type No. HVD145
Laser Mark T5
Package Code SFP
Pin Arrangement
Cathode mark Mark
1 T5 2
1. Cathode 2. Anode
Rev.2.00, Dec 07, 2004, page 1 of 5
Absolute Maximum Ratings
Item Reverse voltage Forward current Power dissipation Junction temperature Storage temperature
VR IF Pd Tj Tstg
Symbol
Ratings 60 50 150 125
- 55 to +125
(Ta = 25°C)
Unit V m A m W °C °C
Electrical Characteristics
(Ta = 25°C)
Item
Symbol
Min
Typ
Max
Unit
Test Condition
Reverse current
Forward voltage
Capacitance
Forward resistance rf
ESD-Capability
-...
