SA21345N
Overview
The SA21345N is an automotive grade 300mA high current capacity linear regulator. It fixes the output voltage at 5V, and features ultra-low ground current and low dropout voltage.
- Wide Input Voltage Range: 4V to 36V
- Fixed 5V Output Voltage
- Low Dropout Voltage of (300mV@300mA)
- Ultra-low Quiescent Current
- Extremely Low Shutdown Current
- Stability with Tantalum or Ceramic Capacitors
- Excellent Load and Line Regulation
- 300mA Maximum Load Current for SO8E
- Enable Control Input
- Over Current Limit Protection
