XL1410 - 2A 380KHz 18V Buck DC to DC Converter

General Description

The XL1410 is a 380KHz fixed frequency PWM buck (step-down) DC/DC converter, capable of driving a 2A load with high efficiency, low ripple and excellent line and load regulation.

Key Features

  • Wide 3.6V to 18V Input Voltage Range.
  • Output Adjustable from 1.222V to 16V.
  • Maximum Duty Cycle 100%.
  • Minimum Drop Out 0.6V.
  • Fixed 380KHz Switching Frequency.
  • 2A Constant Output Current Capability.
  • Internal Optimize Power MOSFET.
  • High efficiency.
  • Excellent line and load regulation.
  • TTL shutdown capability.
  • EN pin with hysteresis function.
  • Built in thermal shutdown function.
  • Built.

📥 Download Datasheet

Datasheet Details

Part number XL1410
Manufacturer XLSEMI
File Size 204.70 KB
Description 2A 380KHz 18V Buck DC to DC Converter
Datasheet download datasheet XL1410 Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
XL1000 20.0-40.0 GHz GaAs MMIC Low Noise Amplifier Mimix Broadband
XL1000-BD Low Noise Amplifier MA-COM
XL1001 17.0-35.0 GHz GaAs MMIC Low Noise Amplifier Mimix Broadband
XL1002 20.0-36.0 GHz GaAs MMIC Low Noise Amplifier Mimix Broadband
XL1002-BD Low Noise Amplifier MA-COM

Other Datasheets by XLSEMI

Part Number Description
XL1192 HBS-Compatible Driver and Receiver Monolithic IC
XL1507 3A 150KHz 30V Buck DC to DC Converter
XL1507A 150KHz 60V 3A Buck DC to DC Converter
XL1509 2A 150KHz 40V Buck DC to DC Converter
XL1509Q 150KHz 45V 2A AEC-Q100 Buck DC to DC Converter

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
2A 380KHz 18V Buck DC to DC Converter Datasheet XL1410 Features „ Wide 3.6V to 18V Input Voltage Range „ Output Adjustable from 1.222V to 16V „ Maximum Duty Cycle 100% „ Minimum Drop Out 0.
