HEDS-9200 Datasheet, Modules, Agilent

HEDS-9200 Features

• Modules
• High Resolution: Up to 2048 Cycles per Revolution
• Up to 8192 Counts per Revolution with 4X Decoding
• Two Channel Quadrature Output
• Low Cost
<

PDF File Details

Part number:

HEDS-9200

Manufacturer:

Agilent

File Size:

312.22kb

Download:

📄 Datasheet

Description:

(heds-9x00) two channel high resolution optical incremental encoder modules. The HEDS-9000 Options T and U and the HEDS-9100 Options B and J are high resolution two channel rotary incremental encoder modules. T

HEDS-9200 Application

• Applications Eg. ABS braking systems, power steering, life support systems and critical care medical equipment. Please contact sales representative
