AT1796 Step-Down Switching Regulator

AT1796 Description

www.DataSheet4U.com AT1796 Preliminary Product Information 150kHz, 3A Step-Down Switching Regulator .
The AT1796 series of regulators are step-down (buck) DC/DC converter, capable of driving a 3A load with excellent line and load regulation.

AT1796 Features

* ․3.3V and 5V output versions ․Guaranteed 3A output load current ․Requires small number ofexternal components ․Excellent line and load regulation ․150kHz fixed frequency internal oscillator ․Built-in TTL On/Off Control ․Low power standby mode, IQ typically 80uA ․Built-in current limit protection ․Bui

AT1796 Applications

* High-efficiency step-down regulator TFT Scalar Board On-card switching regulators Block Diagram Aimtron reserves the right without notice to change this circuitry and specifications. 7F, No.9, PARK AVENUE II, Science-Based Industrial Park, Hsinchu 300,Taiwan, R. O. C. Tel: 886-3-563-0878 Fax: 886-3
