HMC265LM3 Datasheet, Mixer, Analog Devices

HMC265LM3 Features

• Mixer Integrated LO Amplifier: -4 dBm Input Sub-Harmonically Pumped (x2) LO High 2LO/RF Isolation: > 28 dB LM3 SMT Package General Description The HMC265LM3 is a 20 - 31 GHz surface mount sub

PDF File Details

Part number:

HMC265LM3

Manufacturer:

Analog Devices ↗

File Size:

380.14kb

Download:

📄 Datasheet

Description:

Gaas mmic sub-harmonic smt mixer. The HMC265LM3 is a 20 - 31 GHz surface mount sub-harmonically pumped (x2) MMIC mixer downconverter with integrated LO and IF amplifie

HMC265LM3 Application

• Applications The HMC265LM3 is ideal for:
• 20 and 31 GHz Microwave Radios 8
• Downconverter for Point to Point Radios
