PS9814-2 Datasheet, Photocoupler, CEL

PS9814-2 Features

• Photocoupler
• HIGH ISOLATION VOLTAGE BV: 2500 Vr.m.s.
• HIGH COMMON MODE TRANSIENT IMMUNITY CMH, CML = ±20 kV/ µs TYP
• PULSE WIDTH DISTORTION | tPHL - tPLH | = 3 ns TYP

PDF File Details

Part number:

PS9814-2

Manufacturer:

CEL

File Size:

110.82kb

Download:

📄 Datasheet

Description:

8-pin sop high-speed photocoupler. NEC's PS9814-1 and PS9814-2 is an optically coupled high speed, isolator containing a GaAIAs LED on the input side and a photodiode a

PS9814-2 Application

• Applications APPLICATIONS
• MEASUREMENT EQUIPMENT
• PDP
• FACTORY AUTOMATION ELECTRICAL CHARACTERISTICS (TA = -40 to +85°C
