UPC2710TB - SUPER MINIMOLD SILICON MMIC MEDIUM OUTPUT POWER AMPLIFIER

Datasheet Summary

Description

telephone tuners.

This IC is packaged in super minimold package which is smaller than conventional minimold.

This IC is manufactured using NEC’s 20 GHz fT NESATTM lll silicon bipolar process.

Features

  • Supply voltage.
  • Circuit current.
  • Power gain.
  • Medium output power.
  • Upper limit operating frequency.
  • Port impedance.
  • High-density surface mounting : VCC = 4.5 to 5.5 V : ICC = 22 mA TYP. @VCC = 5.0 V : GP = 33 dB TYP. @ f = 500 MHz : PO(sat) = +13.5 dBm TYP. @ f = 500 MHz : fu = 1.0 GHz TYP. @ 3 dB bandwidth : input/output 50 Ω : 6-pin super minimold package (2.0 × 1.25 × 0.9 mm).
