CMT2300A - Ultra Low Power Sub-1GHz RF Transceiver

CMOSTEK

📥 Download Datasheet

CMT2300A Datasheet Preview — Preview of CMT2300A PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number: CMT2300A
Manufacturer: CMOSTEK
File Size: 1.32 MB
Datasheet: CMT2300A-CMOSTEK.pdf
Description: Ultra Low Power Sub-1GHz RF Transceiver

CMT2300A Product details

Description

CMT2300A is an ultra-low power, high performance, OOK (G) FSK RF transceiver suitable for a variety of 140 to 1020 MHz wireless applications.

Features

SoCApplication.
Frequency range: 127 ~1020 MHz.
Modem: OOK, (G)FSK and (G)MSK.
Data rate: 0.5 ~ 300 kbps.
Sensitivity: - 121 dBm 2.0 kbps, FRF = 433.92 MHz -111 dBm 50 kbps, FRF = 433.92 MHz.
Voltage range: 1.8 ~3.6 V.
Transmit current: 23 mA @ 13 dBm, 433.92 MHz, FSK 72 mA @ 20 dBm, 433.92 MHz, FSK.
Rx current:8.5 mA @ 433.92 MHz, FSK (High power mode) 7.2 mA @ 433.92 MHz, FSK (Low power mode).
Super-low Power receive mode.
Sleep current: 300 nA, D.
