CYPD2103 Datasheet, Controller, Cypress Semiconductor

CYPD2103 Features

• Controller
• Integrated transceiver (baseband PHY)
• Integrated UFP (RD), EMCA (RA) termination resistors, and current sources for DFP (RP)
• Supports one USB Type-C port

PDF File Details

Part number:

CYPD2103

Manufacturer:

Cypress Semiconductor

File Size:

1.25MB

Download:

📄 Datasheet

Description:

Type-c port controller. EZ-PD™ CCG2 is a USB Type-C controller that complies with the latest USB Type-C and PD standards. EZ-PD CCG2 provides a complete US

CYPD2103 Application

• Applications EZ-PD CCG2 uses Cypress’s proprietary M0S8 technology with a 32-bit, 48-MHz ARM® Cortex®-M0 processor with 32-KB flash and integrates
