AL1678-10B

500V BUCK LED DRIVER

AL1678-10B Features

* to enhance the system safety and reliability. It has thermal fold back function, which can reduce the output current when the driver’s temperature is higher than the setting value. The AL1678-20B/10B/08B is available in SO-7 package. Pin Assignments (Top View) OUT 1 VCC 2 ROVP 3 GND 4 SO-7 7 Dra

AL1678-10B General Description

The AL1678-20B/10B/08B is a universal AC input (85 to 277 VAC), high efficiency and high accuracy Buck LED driver. The AL167820B/10B/08B topology provides accurate constant current over line and load regulation with tight tolerance ±3%, operating at boundary conduction mode (BCM) to ease in EMI/EMC .

AL1678-10B Datasheet (650.43 KB)

Preview of AL1678-10B PDF

Datasheet Details

Part number:

AL1678-10B

Manufacturer:

DIODES ↗

File Size:

650.43 KB

Description:

500v buck led driver.
