FZT696B Datasheet, Transistor, Diodes

FZT696B Features

• Transistor
• BVCEO > 180V
• IC = 0.5A Continuous Current
• hFE > 500 for High Gain @ 0.1A
• Very Low Saturation Voltage
• Complementary PNP Type: DIODES™ FZ

PDF File Details

Part number:

FZT696B

Manufacturer:

DIODES ↗

File Size:

750.54kb

Download:

📄 Datasheet

Description:

180v npn high voltage transistor.

FZT696B Application

• Applications requiring specific change control (i.e. parts qualified to AEC-Q100/101/104/200, PPAP capable, and manufactured in IATF 16949 certified
