DIM600BSS12-A000 Datasheet, Module, Dynex Semiconductor

DIM600BSS12-A000 Features

• Module I I I 10µs Short Circuit Withstand Non Punch Through Silicon Isolated Copper Baseplate KEY PARAMETERS VCES (typ) VCE(sat)
• (max) IC (max) IC(PK) 1200V 2.2V 600A 1200A
<

PDF File Details

Part number:

DIM600BSS12-A000

Manufacturer:

Dynex Semiconductor

File Size:

192.25kb

Download:

📄 Datasheet

Description:

Single switch igbt module.

DIM600BSS12-A000 Application

• Applications I I Inverters Motor Controllers The Powerline range of high power modules includes half bridge, chopper, dual, single and bi-directio
