XRD9816B Product details

Description

The XRD9814B/9816B is a fully integrated, high-performance analog signal processor/digitizer specifically designed for use in 3-channel linear Charge Coupled Device (CCD) and Contact Image Sensitive (CIS) imaging applications.

Features

14-Bit (XRD9814B) or 16-Bit (XRD9816B) A/D Converter.
Triple-Channel, 2.5 MSPS Color Scan Mode.
Single-Channel, 6 MSPS Monochrome Scan Mode.
Triple Correlated Double Sampler.
Triple 10-Bit Programmable Gain Amplifier.
Triple 10-Bit Offset Compensation DAC.
Fully Differential or Single-Ended Inputs.
CDS or S/H Mode.
Inverting or Non-Inverting Mode.
Internal Voltage Reference.
Serial Control: On Dat.
