2SA671 - PNP Transistor

Product Overview

📥 Download Datasheet

Datasheet preview – 2SA671

Datasheet Details

Part number 2SA671
Manufacturer INCHANGE
File Size 200.99 KB
Description PNP Transistor
Datasheet download datasheet 2SA671 Datasheet
Additional preview pages of the 2SA671 datasheet.

Product details

Description

Low Collector Saturation Voltage- : VCE(SUS)= -1.0V(Max)@ IC= -2.0A DC Current Gain : hFE= 35-320@ IC= -0.5A Complement to Type 2SC1061 Minimum Lot-to-Lot variations for robust device performance and reliable operation APPLICATIONS Designed for use in low frequency power amplifier applications.ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VCBO Collector-Base Voltage -50 V VCEO Collector-Emitter Voltage -50 V VEBO Emitter-Base Voltage -4 V
