Part number: 2SC2307
Manufacturer: INCHANGE
File Size: 192.85KB
Download: 📄 Datasheet
Description: NPN Transistor
*Designed for switching regulator and general purpose
applications
ABSOLUTE MAXIMUM RATINGS(Ta=25℃)
SYMBOL
PARAME.
*Collector-Emitter Breakdown Voltage-
V(BR)CEO= 400V(Min)
*High Switching Speed
*Minimum Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
*Designed for switching regulator and general purpose
app.
