2SC2877 - NPN Transistor

2SC2877 Description

isc Silicon NPN Power Transistor .
Collector-Emitter Breakdown Voltage- V(BR)CEO= 40V (Min). Good Linearity of hFE. Complement to Type 2SA1217. Minimum Lot-to-Lot varia.

2SC2877 Applications

* Designed for audio frequency power amplifier and low speed switching applications.
* Suitable for output stage of 5 watts car radio and car stereo. ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VCBO Collector-Base Voltage 40 V VCEO Collector-Emitter Voltage 40 V VE

📥 Download Datasheet

Preview of 2SC2877 PDF
datasheet Preview Page 2

Datasheet Details

Part number
2SC2877
Manufacturer
INCHANGE
File Size
192.91 KB
Datasheet
2SC2877-INCHANGE.pdf
Description
NPN Transistor
