AOD242 - N-Channel MOSFET

AOD242 Description

isc N-Channel MOSFET Transistor AOD242 .
Designed for use in switch mode power supplies and general purpose applications.

AOD242 Features

* Drain Current
* ID=54A@ TC=25℃
* Drain Source Voltage- : VDSS=40V(Min)
* Static Drain-Source On-Resistance : RDS(on) = 5.8mΩ(Max)
* 100% avalanche tested

AOD242 Applications

* ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VDSS Drain-Source Voltage 40 V VGS Gate-Source Voltage-Continuous ±20 V ID Drain Current-Continuous 54 A IDM Drain Current-Single Pluse 165 A PD Total Dissipation @TC=25℃ 53.5 W TJ Max. Operating Junction Tempera

📥 Download Datasheet

Preview of AOD242 PDF
datasheet Preview Page 2

Datasheet Details

Part number
AOD242
Manufacturer
INCHANGE
File Size
261.10 KB
Datasheet
AOD242-INCHANGE.pdf
Description
N-Channel MOSFET
