FJA4210 PNP Transistor

FJA4210 Description

isc Silicon PNP Power Transistor FJA4210 .
Collector-Emitter Breakdown Voltage- : V(BR)CEO= -140V(Min). DC Current Gain- : hFE= 50(Min)@ IC= -3A. Complement to Type FJA4310. Mi.

FJA4210 Applications

* Designed for audio and general purpose applications. ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VCBO Collector-Base Voltage -200 V VCEO Collector-Emitter Voltage -140 V VEBO Emitter-Base Voltage -6 V IC Collector Current-Continuous -10 A IB Base Current-C

📥 Download Datasheet

Preview of FJA4210 PDF
datasheet Preview Page 2

Datasheet Details

Part number
FJA4210
Manufacturer
INCHANGE
File Size
197.83 KB
Datasheet
FJA4210-INCHANGE.pdf
Description
PNP Transistor
