STW20N65M5

N-Channel MOSFET

STW20N65M5 Features

* Drain Current

* ID= 18A@ TC=25℃

* Drain Source Voltage- : VDSS= 650V(Min)

* Static Drain-Source On-Resistance : RDS(on) = 190mΩ(Max)

* 100% avalanche tested

* Minimum Lot-to-Lot variations for robust device performance and reliable operation DESCRIPTION

* Low Drain-Source

STW20N65M5 General Description


*Low Drain-Source On-Resistance APPLICATIONS
*Switching application ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VDSS Drain-Source Voltage VGS Gate-Source Voltage-Continuous ID Drain Current-Continuous IDM Drain Current-Single Pluse PD Total Dissipation @TC=25℃ TJ Max. O.

STW20N65M5 Datasheet (276.06 KB)

Preview of STW20N65M5 PDF

Datasheet Details

Part number:

STW20N65M5

Manufacturer:

INCHANGE

File Size:

276.06 KB

Description:

N-channel mosfet.
