SW6106 - Bidirectional Fast Charge Power Bank

Product Overview

📥 Download Datasheet

SW6106 Bidirectional Fast Charge Power Bank by ISMARTWARE - Datasheet Preview — Datasheet preview – SW6106

Datasheet Details

Part number	SW6106
Manufacturer	ISMARTWARE
File Size	706.40 KB
Description	Bidirectional Fast Charge Power Bank
Datasheet	SW6106 Datasheet
Additional preview pages of the SW6106 datasheet.

Product details

Description

The SW6106 is a highly integrated power management IC for fast charge power bank application. Power Bank Battery Powered Device 3.

Features

Switching Charger.
Current up to 4A , Efficiency up to 96%.
Support 4.2/4.3/4.35/4.4 Battery Voltage.
Support Battery NTC Protection.
Thermal Regulation.
Synchronous Boost.
Power up to 18W, Efficiency up to 95%.
Support Wire Drop Compensation.
Load Insert Detect and Auto Turn on.
Light Load Detect and Auto Turn off.
Output Fast Charge Protocol.
Support PD3.0/PD2.0.
Support QC3.0.
