SW6005 Datasheet - ISMARTWARE

SW6005 5V/2.4A Type-C Solution Power Bank

The SW6005 is a highly integrated power management IC for type-c power bank application, and supports A+B+C+L or A+A+B+C four ports. It integrates 2.4A switching charger, 2.4A synchronous boost, fuel gauge, segment/led driver and power controller. With simple external components, The SW6005 provide.

SW6005 Features

* Switching Charger

* Current up to 2.4A , Efficiency up to 96%

* Support 4.2/4.35/4.4/4.5V Battery Voltage

* Support JEITA

* Thermal Regulation

* Synchronous Boost

* Current up to 2.4A, Efficiency up to 95%

* Load Insert Detect and Li

SW6005 Datasheet (842.02 KB)

SW6005 Datasheet Preview — Preview of SW6005 PDF

Datasheet Details

Part number:

SW6005

Manufacturer:

ISMARTWARE

File Size:

842.02 KB

Description:

5v/2.4a type-c solution power bank.
