IXGR72N60B3H1 Datasheet, Igbt, IXYS

IXGR72N60B3H1 Features

• Igbt
• Silicon Chip on Direct-Copper Bond (DCB) Substrate
• Isolated Mounting Surface Optimized for Low Conduction and Switching Losses
• 2500V~ Electrical Isolation

PDF File Details

Part number:

IXGR72N60B3H1

Manufacturer:

IXYS

File Size:

255.90kb

Download:

📄 Datasheet

Description:

Medium speed low vsat pt igbt.

IXGR72N60B3H1 Application

• Applications
• Power Inverters
• UPS
• Motor Drives
• SMPS
• PFC Circuits
• Battery Chargers
