IDTQS3306A - HIGH-SPEED CMOS DUAL BUS SWITCH

Product Overview

Integrated Device Technology

Datasheet Details

Part number	IDTQS3306A
Manufacturer	Integrated Device Technology
File Size	200.98 KB
Description	HIGH-SPEED CMOS DUAL BUS SWITCH
Datasheet	IDTQS3306A Datasheet
Additional preview pages of the IDTQS3306A datasheet.

Product details

Description

The QS3306A provides a set of two high-speed low resistance (3Ω typical) CMOS switches connecting inputs to outputs without propagation delay and without generating additional ground bounce noise.

Features

Enhanced N channel FET with no inherent diode to Vcc Very low ON Resistance (3Ω typical) Fast turn-on/turn-off time Available in 8-pin SOIC Package (S1) Undershoot clamp diodes on all switch and control inputs Zero propagation delay, zero added ground bounce IDTQS3306A.
