IDTQS3384 - HIGH-SPEED CMOS 10-BIT BUS SWITCH

Product Overview

Integrated Device

Datasheet Details

Part number	IDTQS3384
Manufacturer	Integrated Device
File Size	206.95 KB
Description	HIGH-SPEED CMOS 10-BIT BUS SWITCH
Datasheet	IDTQS3384 Datasheet
Additional preview pages of the IDTQS3384 datasheet.

Product details

Description

Enhanced N channel FET with no inherent diode to Vcc 5Ω bidirectional switches connect inputs to outputs Zero propagation delay, zero added ground bounce Undershoot clamp diodes on all switch and control inputs Two enables control five bits each Available in SOIC, QSOP, and TSSOP packages The QS3384 provides a set of ten high-speed CMOS, TTL-compatible bus switches.The low ON resistance of QS3384 allows inputs to be connected to outputs without adding propagation delay and without generating
