IRFH5220PBF Datasheet, mosfet equivalent, International Rectifier

IRFH5220PBF Features

• Mosfet Features Benefits Low RDSon Low Thermal Resistance to PCB (≤ 1.2°C/W) 100% Rg tested Low Profile (≤ 0.9 mm) Industry-Standard Pinout Compatible with Existing Surface Mount Techniques R

PDF File Details

Part number:

IRFH5220PBF

Manufacturer:

International Rectifier

File Size:

250.77kb

Download:

📄 Datasheet

Description:

Hexfet power mosfet.

IRFH5220PBF Application

• Applications
• Secondary Side Synchronous Rectification
• Inverters for DC Motors
• DC-DC Brick Applications
• Boost
