SI2301DS-HF - P-Channel MOSFET

Product Overview

Kexin

📥 Download Datasheet

SI2301DS-HF P-Channel MOSFET by Kexin - Datasheet Preview — Datasheet preview – SI2301DS-HF

Datasheet Details

Part number	SI2301DS-HF
Manufacturer	Kexin
File Size	1.46 MB
Description	P-Channel MOSFET
Datasheet	SI2301DS-HF Datasheet
Additional preview pages of the SI2301DS-HF datasheet.

Product details

Features

s.
VDS (V) =-20V.
RDS(ON) ＜ 130mΩ (VGS =-4.5V).
RDS(ON) ＜ 190mΩ (VGS =-2.5V).
Pb.
Free Package May be Available. The G.
Suffix Denotes a Pb.
Free Lead Finish G1 S2 3D +0.12.4 -0.1 SOT-23 2.9 +0.1 -0.1 0.4 +0.1 -0.1 3 12 0.95 +0.1 -0.1 1.9 +0.1 -0.1 0-0.1 +0.10.38 -0.1 +0.10.97 -0.1 +0.11.3 -0.1 0.55 0.4 MOSFET Unit: mm 0.1 +0.05 -0.01 1.Gate 2.Source 3.Drain.
Absolute Maximum Ratings Ta = 25℃ Parameter Symbol Drain-Source Voltage VDS.
