MAPC-A3005-AS Datasheet, Transistor, MACOM

MAPC-A3005-AS Features

• Transistor
• Saturated Power: 9 W
• Drain Efficiency: 55 %
• Small Signal Gain: 14 dB
• Lead-Free Air Cavity Ceramic Package
• RoHS
• Compliant Appli

PDF File Details

Part number:

MAPC-A3005-AS

Manufacturer:

MACOM

File Size:

873.10kb

Download:

📄 Datasheet

Description:

Gan on sic transistor. The MAPC-A3005-AS is a 9 W packaged, unmatched transistor utilizing a high performance, 0.15 µm GaN on SiC production process. This t

MAPC-A3005-AS Application

• Applications
• Avionics - TACAN, DME, IFF
• Military Radio
• L, S, C-Band Radar
• Electronic Warfare
• ISM <
