SP336E - 3.3V / 5V PROGRAMMABLE RS-232/RS-485/RS-422 SERIAL TRANSCEIVER

Product Overview

MaxLinear

📥 Download Datasheet

SP336E 3.3V / 5V PROGRAMMABLE RS-232/RS-485/RS-422 SERIAL TRANSCEIVER by MaxLinear - Datasheet Preview — Datasheet preview – SP336E

Datasheet Details

Part number	SP336E
Manufacturer	MaxLinear
File Size	1.47 MB
Description	3.3V / 5V PROGRAMMABLE RS-232/RS-485/RS-422 SERIAL TRANSCEIVER
Datasheet	SP336E Datasheet
Additional preview pages of the SP336E datasheet.

Product details

Description

The SP336E is a monolithic serial multi-transceiver device that contains both RS-232 and RS-485/RS422 line drivers and receivers.

Features

3.3V or 5V Single Supply Operation.
Robust ±15kV ESD Protection (IEC 61000-4-2 Air Gap).
Software Selectable Mode Selection.
Up to 4 Drivers, 4 Receivers RS-232/V.28.
Up to 2 Drivers, 2 Receivers RS-485/RS-422.
Full or Half Duplex Configurations.
1/8th Unit Load, up to 256 receivers on bus.
Mixed RS-232/RS-485 modes.
Pin Programmable Slew Rate for Reduced EMI.
RS-485 Advanced Failsafe on Open, Short or Terminated Lines.
Diagnostic Loop-Back.
